Epson C13T544400

CPU 1.Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/ Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1155 package. 2.L3 cache varies with CPU (Some Intel® Core™ processors require a graphic card, please refer "CPU support List" for more information.) Chipset 1.Intel® P67 Express Chipset Memory 1.4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory * Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB. 2.Dual channel memory architecture 3.Support for DDR3 2133/1866/1600/1333/1066 MHz memory modules 4.Support for non-ECC memory modules 5.Support for Extreme Memory Profile (XMP) memory modules (Please refer "Memory Support List" for more information.) Audio 1.Realtek audio codec 2.High Definition Audio 3.2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver. 4.Support for S/PDIF Out LAN 1.1 x Realtek RTL8111E chip (10/100/1000 Mbit) Expansion Slots 1.1 x PCI Express x16 slot, running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 2.1 x PCI Express x16 slot, running at x4 (PCIEX4) * When the PCIEX1_2 or PCIEX1_3 slot is populated with an expansion card, the PCIEX4 slot will operate at up to x1 mode. 3.3 x PCI Express x1 slots (All PCI Express slots conform to PCI Express 2.0 standard.) 4.2 x PCI slots Multi-Graphics Technology 1.Support for AMD CrossFireX™ technology * The PCIEX16 slot operates at up to x4 mode when AMD CrossFireX™ is enabled. Storage Interface Chipset: 1.2 x SATA 6Gb/s connectors (SATA3 0, 1) supporting up to 2 SATA 6Gb/s devices 2.4 x SATA 3Gb/s connectors (SATA2 2~5) supporting up to 4 SATA 3Gb/s devices 3.Support for RAID 0, RAID 1, RAID 5, and RAID 10 * When a RAID set is built across the SATA 6Gb/s and SATA 3Gb/s channels, the system performance of the RAID set may vary depending on the devices being connected. USB Chipset: 1.Up to 10 USB 2.0/1.1 ports (4 on the back panel, 6 via the USB brackets connected to the internal USB headers) Etron EJ168 chip: 1.Up to 2 USB 3.0/2.0 ports on the back panel. Internal I/O Connectors 1.1 x 24-pin ATX main power connector 2.1 x 4-pin ATX 12V power connector 3.2 x SATA 6Gb/s connectors 4.4 x SATA 3Gb/s connectors 5.1 x CPU fan header 6.2 x system fan headers 7.1 x power fan header 8.1 x front panel header 9.1 x front panel audio header 10.1 x S/PDIF Out header 11.3 x USB 2.0/1.1 headers 12.1 x clearing CMOS jumper 13.1 x Trusted Platform Module (TPM) header Back Panel Connectors 1.1 x PS/2 keyboard/mouse port 2.1 x parallel port 3.1 x serial port 4.1 x optical S/PDIF Out connector 5.4 x USB 2.0/1.1 ports 6.2 x USB 3.0/2.0 ports 7.1 x RJ-45 port 8.3 x audio jacks (Line In/Line Out/Microphone) I/O Controller 1.iTE IT8728 chip H/W Monitoring 1.System voltage detection 2.CPU/System temperature detection 3.CPU/System/Power fan speed detection 4.CPU overheating warning 5.CPU/System/Power fan fail warning 6.CPU/System fan speed control * Whether the CPU/system fan speed control function is supported will depend on the CPU/system cooler you install. BIOS 1.2 x 32 Mbit flash 2.Use of licensed AWARD BIOS 3.Support for DualBIOS™ 4.PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b Unique Features 1.Support for @BIOS 2.Support for Q-Flash 3.Support for Xpress BIOS Rescue 4.Support for Download Center 5.Support for Xpress Install 6.Support for Xpress Recovery2 7.Support for EasyTune * Available functions in EasyTune may differ by motherboard model. 8.Support for Dynamic Energy Saver™ 2 9.Support for Smart 6™ 10.Support for Auto Green 11.Support for eXtreme Hard Drive (X.H.D) 12.Support for ON/OFF Charge 13.Support for Cloud OC 14.Support for 3TB+ Unlock 15.Support for TouchBIOS 16.Support for Q-Share Bundle Software 1.Norton Internet Security (OEM version) Operating System 1.Support for Microsoft® Windows® 7/Vista/XP Form Factor 1.ATX Form Factor; 30.5cm x 21.5cm Remark 1.Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. 2.Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.
